WS2812/WS2811B RGBIC COB LED Light Strip 720Leds/m

1. 360/576/720 chips are arranged in a linear way, integrated package, with uniform light color and no light spot;
2. High thermal conductivity flexible circuit board design, can be bent at will, convenient for installation;
3. The LED chip is directly mounted on the FPC, and the luminous angle can reach 180 degrees;
4. DC24V constant voltage design, safe low voltage, low voltage drop, standard cascade 5m;
5. The back is pasted with high viscosity heat conduction double-sided adhesive tape, which is convenient for installation and firm and durable for pasting;
6. LED light source, energy-saving and environmental protection, in line with national environmental standards.

Description

Product Applications

Input Voltage:DC12V/DC24V.
IC Type: COB RGB WS2811 IC./WS2812B
Wattage: 21W/m.
FPCB Width: 10mm/12mm.
LED Quantity:360 576 720 LEDs/M.
Cutting Length: every 50mm.
Individually Addressable: every 50mm can be unique controlled.
Color Rendering Index: Ra>90.
Operation Temperature: -20℃-+45℃.
Storage Temperature: -20℃-+60℃.
View Angle: 180°

Specifications

Model No FPC width Voltage CRI Cutting Length LED Type LEDs/m Lumen Efficiency Power Size CCT
COB PIXEL STRIP 10mm 12V 80 6 COB 720 28lm/m 90lm/w 21w/m 12mm can be OEM

Tutorial video

  • How to install and cut led light strips
  • How to install and cut led light strips
